Networks 107
If the user selects to configure the proxy server manually, the desired settings can be
specified in the following fields.
• Proxy server is a text box for defining the address of the server.
• Port is a text box for defining the port of the server.
• Username is a text box for defining the user name to access the proxy server.
• Password is a text box for the password to access the proxy server.
• No proxy for is a text box to list all the IP addresses or domains which can be
accessed directly, without contacting the proxy server.
Mail servers (outgoing) panel
The Mail servers (outgoing) panel contains the following components:
• Primary server is a text box for defining the primary server for the SMTP service.
• Secondary server is a text box for defining the secondary server for the SMTP
service.
• Port is a text box for defining the SMTP port for the SMTP service. The default value
is 25. Both primary and secondary mail servers have their own ports to be configured.
• Username is a text box for defining the user name for the SMTP service. Both primary
and secondary mail servers have their authentication settings to be configured. The
Username and Password boxes can be left empty if the SMTP server does not require
authentication.
• Password is a text box for defining the password for the SMTP service. Both primary
and secondary mail servers have their authentication settings to be configured.
• Enable SSL encryption is a check box for enabling the SSL encryption for the SMTP
service. Both primary and secondary mail servers have their encryption settings to be
configured.
DHCP
For instructions on setting up a DHCP server, see Connecting a local PC to the NETA-21
in the DHCP server mode.
HTTP/HTTPS
HTTP is the default protocol setting in the NETA-21. To switch from HTTP to HTTPS edit
the address from http://192.168.230.1 to https://192.168.230.1. This can also be done by
selecting the Prefer HTTPS check box in Network services.
