Security 165
User role - Select External account from the drop down
Language - Select the desired language
Comment - Provide comments if required.
Notes:
• Local user accounts will be left active in addition to the external RADIUS user
accounts.
• Local accounts should have strong passwords.
• When RADIUS server is unreachable due to network unavailability or other reasons,
local login will be enabled once per failed RADIUS login even if the local logins are
disabled in Security settings.
3. In the User & password section, enter the desired user name in the User name field.
The below patterns are allowed for User name:
4. After the above changes, the Login dialog box displays the option to login with
RADIUS login method.
Pattern Login user Example
* Any valid user johdoe
john.doe@example.com
\\JDOE
*@example.com Any user at specific
domain
john.doe@example.com
user name Only one specific user johndo
john.doe@example.com
