ABB REF615 L User Manual

Name Type Default Description
IN6 BOOLEAN 0=False Input 6
IN7 BOOLEAN 0=False Input 7
IN8 BOOLEAN 0=False Input 8
Table 134: TONGAPC Output signals
Name Type Description
Q1 BOOLEAN Output 1
Q2 BOOLEAN Output 2
Q3 BOOLEAN Output 3
Q4 BOOLEAN Output 4
Q5 BOOLEAN Output 5
Q6 BOOLEAN Output 6
Q7 BOOLEAN Output 7
Q8 BOOLEAN Output 8
3.14.5.4 Settings
Table 135: TONGAPC Non group settings
Parameter
Values (Range) Unit Step Default Description
On delay time 1 0...3600000 ms 10 0 On delay time
On delay time 2 0...3600000 ms 10 0 On delay time
On delay time 3 0...3600000 ms 10 0 On delay time
On delay time 4 0...3600000 ms 10 0 On delay time
On delay time 5 0...3600000 ms 10 0 On delay time
On delay time 6 0...3600000 ms 10 0 On delay time
On delay time 7 0...3600000 ms 10 0 On delay time
On delay time 8 0...3600000 ms 10 0 On delay time
3.14.5.5 Technical data
Table 136: TONGAPC Technical data
Characteristic
Value
Operate time accuracy ±1.0% of the set value or ±20 ms
Section 3 1YHT530004D05 D
Basic functions
126 615 series
Technical Manual

ABB REF615 L Specifications

General

Type	Feeder Protection Relay
Rated Frequency	50/60 Hz
Weight	Approx. 1.5 kg
Communication Protocols	IEC 61850, Modbus RTU, DNP3
Protection Functions	Overcurrent, Earth fault, Thermal overload, Under/Over voltage, Under/Over frequency
Enclosure	IP20
