Name Type Description
OKPOS BOOLEAN Apparatus position is ok
OPEN_ENAD BOOLEAN Opening is enabled based on the input status
CLOSE_ENAD BOOLEAN Closing is enabled based on the input status
Table 593: ESXSWI Output signals
Name Type Description
SELECTED BOOLEAN Object selected
EXE_OP BOOLEAN Executes the command for open direction
EXE_CL BOOLEAN Executes the command for close direction
OPENPOS BOOLEAN Apparatus open position
CLOSEPOS BOOLEAN Apparatus closed position
OKPOS BOOLEAN Apparatus position is ok
OPEN_ENAD BOOLEAN Opening is enabled based on the input status
CLOSE_ENAD BOOLEAN Closing is enabled based on the input status
9.1.7 Settings
Table 594: CBXCBR Non group settings
Parameter
Values (Range) Unit Step Default Description
Operation 1=on
5=off
1=on Operation mode on/off
Select timeout 10000...300000 ms 10000 60000 Select timeout in ms
Pulse length 10...60000 ms 1 100 Open and close pulse length
Operation counter 0...10000 0 Breaker operation cycles
Control model 0=status-only
1=direct-with-
normal-security
4=sbo-with-
enhanced-security
4=sbo-with-
enhanced-security
Select control model
Adaptive pulse 0=False
1=True
1=True Stop in right position
Event delay 0...10000 ms 1 100 Event delay of the intermediate position
Operation timeout 10...60000 ms 500 Timeout for negative termination
Table 595: DCXSWI Non group settings
Parameter
Values (Range) Unit Step Default Description
Operation 1=on
5=off
1=on Operation mode on/off
Select timeout 10000...300000 ms 10000 60000 Select timeout in ms
Pulse length 10...60000 ms 1 100 Open and close pulse length
Operation counter 0...10000 0 Breaker operation cycles
Table continues on next page
Section 9 1YHT530004D05 D
Control functions
674 615 series
Technical Manual
