5.5.7 Settings
Table 483: ESMGAPC Group settings
Parameter Values (Range) Unit Step Default Description
Motor standstill A 0.05...0.20 xIn 0.01 0.12 Current limit to check for motor standstill
condition
Table 484: ESMGAPC Non group settings
Parameter Values (Range) Unit Step Default Description
Operation 1=on
5=off
1=on Operation Off / On
5.5.8 Monitored data
Table 485: ESMGAPC Monitored data
Name Type Values (Range) Unit Description
T_ST_EMERG Timestamp Emergency start
activation timestamp
ESMGAPC Enum 1=on
2=blocked
3=test
4=test/blocked
5=off
Status
5.5.9 Technical data
Table 486: ESMGAPC Technical data
Characteristic
Value
Operation accuracy At the frequency f = f
n
±1.5% of the set value or ±0.002 × U
n
5.6 Switch on to fault control CBRSOF
5.6.1 Identification
Function description
IEC 61850
identification
IEC 60617
identification
ANSI/IEEE C37.2
device number
Switch on to fault control CBRSOF SOTF SOTF
1YHT530004D05 D Section 5
Protection related functions
615 series 563
Technical Manual

ABB REF615 L Specifications

General

Type	Feeder Protection Relay
Rated Frequency	50/60 Hz
Weight	Approx. 1.5 kg
Communication Protocols	IEC 61850, Modbus RTU, DNP3
Protection Functions	Overcurrent, Earth fault, Thermal overload, Under/Over voltage, Under/Over frequency
Enclosure	IP20
