Page #566 background imageLoading...
Page #566 background image
Parameter Values (Range) Unit Step Default Description
Signal 5 mode 1=In use
2=In use, alarm sel.
3=Not in use
1=In use Operation mode for signal 5
Signal 6 mode 1=In use
2=In use, alarm sel.
3=Not in use
1=In use Operation mode for signal 6
Signal 7 mode 1=In use
2=In use, alarm sel.
3=Not in use
1=In use Operation mode for signal 7
Signal 8 mode 1=In use
2=In use, alarm sel.
3=Not in use
1=In use Operation mode for signal 8
Pulse time 1 0...60000 ms 1 0 Minimum pulse time for received signal 1
Pulse time 2 0...60000 ms 1 0 Minimum pulse time for received signal 2
Pulse time 3 0...60000 ms 1 0 Minimum pulse time for received signal 3
Pulse time 4 0...60000 ms 1 0 Minimum pulse time for received signal 4
Pulse time 5 0...60000 ms 1 0 Minimum pulse time for received signal 6
Pulse time 6 0...60000 ms 1 0 Minimum pulse time for received signal 6
Pulse time 7 0...60000 ms 1 0 Minimum pulse time for received signal 7
Pulse time 8 0...60000 ms 1 0 Minimum pulse time for received signal 8
Table 479: BSTGGIO Non group settings
Parameter
Values (Range) Unit Step Default Description
Alarm mode 1=Any of selected
2=All of selected
1=Any of selected Selects the used alarm logic mode for
activating SEND_SIG_A and
RECV_SIG_A
5.4.8 Technical data
Table 480: BSTGGIO Technical data
Characteristic
Value
Signalling delay Fiber optic link < 5 ms
Galvanic pilot
wire link < 10 ms
5.5 Emergency startup ESMGAPC
5.5.1 Identification
Functional description
IEC 61850
identification
IEC 60617
identification
ANSI/IEEE C37.2
device number
Emergency startup ESMGAPC ESTART ESTART
Section 5 1YHT530004D05 D
Protection related functions
560 615 series
Technical Manual
