Table 455: MAPGAPC Non group settings
Parameter Values (Range) Unit Step Default Description
Operation 1=on
5=off
1=on Operation Off / On
Operation mode 1=Over
2=Under
1=Over Operation mode
Reset delay time 0...60000 ms 100 0 Reset delay time
Absolute hysteresis 0.01...100.00 0.01 0.10 Absolute hysteresis for operation
4.9.8 Monitored data
Table 456: MAPGAPC Monitored data
Name Type Values (Range) Unit Description
START_DUR FLOAT32 0.00...100.00 % Ratio of start time /
operate time
MAPGAPC Enum 1=on
2=blocked
3=test
4=test/blocked
5=off
Status
4.9.9 Technical data
Table 457: MAPGAPC Technical data
Characteristic
Value
Operation accuracy ±1.0% of the set value or ±20 ms
Section 4 1YHT530004D05 D
Protection functions
536 615 series
Technical Manual

ABB REF615 L Specifications

General

Type	Feeder Protection Relay
Rated Frequency	50/60 Hz
Weight	Approx. 1.5 kg
Communication Protocols	IEC 61850, Modbus RTU, DNP3
Protection Functions	Overcurrent, Earth fault, Thermal overload, Under/Over voltage, Under/Over frequency
Enclosure	IP20
