8.1.11.4 Settings
Table 571: PEMMXU Non group settings
Parameter Values (Range) Unit Step Default Description
Operation 1=on
5=off
1=on Operation Off / On
Power unit Mult 3=Kilo
6=Mega
3=Kilo Unit multiplier for presentation of the
power related values
Energy unit Mult 3=Kilo
6=Mega
3=Kilo Unit multiplier for presentation of the
energy related values
Active power Dir 1=Forward
2=Reverse
1=Forward Direction of active power flow: Forward,
Reverse
Reactive power Dir 1=Forward
2=Reverse
1=Forward Direction of reactive power flow:
Forward, Reverse
Forward Wh Initial 0...999999999 1 0 Preset Initial value for forward active
energy
Reverse Wh Initial 0...999999999 1 0 Preset Initial value for reverse active
energy
Forward VArh Initial 0...999999999 1 0 Preset Initial value for forward reactive
energy
Reverse VArh Initial 0...999999999 1 0 Preset Initial value for reverse reactive
energy
8.1.11.5 Monitored data
Table 572: PEMMXU Monitored data
Name
Type Values (Range) Unit Description
S-kVA FLOAT32 -999999.9...9999
99.9
kVA Total Apparent Power
P-kW FLOAT32 -999999.9...9999
99.9
kW Total Active Power
Q-kVAr FLOAT32 -999999.9...9999
99.9
kVAr Total Reactive Power
PF FLOAT32 -1.00...1.00 Average Power factor
Max demand S FLOAT32 -999999.9...9999
99.9
kVA Maximum demand value
of apparent power
Min demand S FLOAT32 -999999.9...9999
99.9
kVA Minimum demand value
of apparent power
Max demand P FLOAT32 -999999.9...9999
99.9
kW Maximum demand value
of active power
Min demand P FLOAT32 -999999.9...9999
99.9
kW Minimum demand value
of active power
Max demand Q FLOAT32 -999999.9...9999
99.9
kVAr Maximum demand value
of reactive power
Min demand Q FLOAT32 -999999.9...9999
99.9
kVAr Minimum demand value
of reactive power
Time max dmd S Timestamp Time of maximum
demand
Table continues on next page
Section 8 1YHT530004D05 D
Measurement functions
648 615 series
Technical Manual
