To navigate between the options, use and .
• HMI menu paths are presented in bold.
Select Main menu/Settings.
• LHMI messages are shown in Courier font.
To save the changes in non-volatile memory, select Yes and press .
• Parameter names are shown in italics.
The function can be enabled and disabled with the Operation setting.
• Parameter values are indicated with quotation marks.
The corresponding parameter values are "On" and "Off".
• IED input/output messages and monitored data names are shown in Courier font.
When the function starts, the START output is set to TRUE.
1.4.3 Functions, codes and symbols
All available functions are listed in the table. All of them may not be applicable to
all products.
Table 1: Functions included in the IEDs
Function IEC 61850 IEC 60617 IEC-ANSI
Protection
Three-phase non-directional overcurrent protection,
low stage, instance 1
PHLPTOC1 3I> (1) 51P-1 (1)
Three-phase non-directional overcurrent protection,
low stage, instance 2
PHLPTOC2 3I> (2) 51P-1 (2)
Three-phase non-directional overcurrent protection,
high stage, instance 1
PHHPTOC1 3I>> (1) 51P-2 (1)
Three-phase non-directional overcurrent protection,
high stage, instance 2
PHHPTOC2 3I>> (2) 51P-2 (2)
Three-phase non-directional overcurrent protection,
instantaneous stage, instance 1
PHIPTOC1 3I>>> (1) 50P/51P (1)
Three-phase non-directional overcurrent protection,
instantaneous stage, instance 2
PHIPTOC2 3I>>> (2) 50P/51P (2)
Three-phase directional overcurrent protection, low
stage, instance 1
DPHLPDOC1 3I> -> (1) 67-1 (1)
Three-phase directional overcurrent protection, low
stage, instance 2
DPHLPDOC2 3I> -> (2) 67-1 (2)
Three-phase directional overcurrent protection, high
stage
DPHHPDOC1 3I>> -> 67-2
Three-phase non-directional overcurrent protection
that contains three independent phase-segregated
timers, low stage, instance 1
PH3LPTOC1 3I> (1) 51P-1 (1)
Three-phase non-directional overcurrent protection
that contains three independent phase-segregated
timers, low stage, instance 2
PH3LPTOC2 3I> (2) 51P-1 (2)
Three-phase non-directional overcurrent protection
that contains three independent phase-segregated
timers, high stage, instance 1
PH3HPTOC1 3I>> (1) 51P-2 (1)
Three-phase non-directional overcurrent protection
that contains three independent phase-segregated
timers, high stage, instance 2
PH3HPTOC2 3I>> (2) 51P-2 (2)
Three-phase non-directional overcurrent protection
that contains three independent phase-segregated
timers, instantaneous stage, instance 1
PH3IPTOC1 3I>>> (1) 50P/51P (1)
Three-phase directional overcurrent protection that
contains three independent phase-segregated timers,
low stage, instance 1
DPH3LPDOC1 3I> -> (1) 67-1 (1)
Table continues on next page
Section 1 1YHT530004D05 D
Introduction
28 615 series
Technical Manual
