3.14.9.3 Signals
Table 147: SPCGGIO Input signals
Name Type Default Description
BLOCK BOOLEAN 0=False Block signal for activating the blocking mode
IN1 BOOLEAN 0=False Input of control point 1
IN2 BOOLEAN 0=False Input of control point 2
IN3 BOOLEAN 0=False Input of control point 3
IN4 BOOLEAN 0=False Input of control point 4
IN5 BOOLEAN 0=False Input of control point 5
IN6 BOOLEAN 0=False Input of control point 6
IN7 BOOLEAN 0=False Input of control point 7
IN8 BOOLEAN 0=False Input of control point 8
IN9 BOOLEAN 0=False Input of control point 9
IN10 BOOLEAN 0=False Input of control point 10
IN11 BOOLEAN 0=False Input of control point 11
IN12 BOOLEAN 0=False Input of control point 12
IN13 BOOLEAN 0=False Input of control point 13
IN14 BOOLEAN 0=False Input of control point 14
IN15 BOOLEAN 0=False Input of control point 15
IN16 BOOLEAN 0=False Input of control point 16
Table 148: SPCGGIO Output signals
Name
Type Description
O1 BOOLEAN Output 1 status
O2 BOOLEAN Output 2 status
O3 BOOLEAN Output 3 status
O4 BOOLEAN Output 4 status
O5 BOOLEAN Output 5 status
O6 BOOLEAN Output 6 status
O7 BOOLEAN Output 7 status
O8 BOOLEAN Output 8 status
O9 BOOLEAN Output 9 status
O10 BOOLEAN Output 10 status
O11 BOOLEAN Output 11 status
O12 BOOLEAN Output 12 status
O13 BOOLEAN Output 13 status
O14 BOOLEAN Output 14 status
O15 BOOLEAN Output 15 status
O16 BOOLEAN Output 16 status
1YHT530004D05 D Section 3
Basic functions
615 series 135
Technical Manual

ABB REF615 L Specifications

General

Type	Feeder Protection Relay
Rated Frequency	50/60 Hz
Weight	Approx. 1.5 kg
Communication Protocols	IEC 61850, Modbus RTU, DNP3
Protection Functions	Overcurrent, Earth fault, Thermal overload, Under/Over voltage, Under/Over frequency
Enclosure	IP20
