3.14.8.5 Monitored data
Table 146: CONTROL Monitored data
Parameter Type Values (Range) Unit Description
Command
response
ENUM 1 = "Select open"
2 = "Select close"
3 = "Operate
open"
4 = "Operate
close"
5 = "Direct open"
6 = "Direct close"
7 = "Cancel"
8 = "Position
reached"
9 = "Position
timeout"
10 = "Object
status only"
11 = "Object
direct"
12 = "Object
select"
13 = "RL local
allowed"
14 = "RL remote
allowed"
15 = "RL off"
16 = "Function off"
17 = "Function
blocked"
18 = "Command
progress"
19 = "Select
timeout"
20 = "Missing
authority"
21 = "Close not
enabled"
22 = "Open not
enabled"
23 = "Internal
fault"
24 = "Already
close"
25 = "Wrong
client"
26 = "RL station
allowed"
27 = "RL change"
Latest command
response
LR state ENUM 1 = "OFF"
2 = "Local"
3 = "Remote"
4 = "Station"
LR state
monitoring for
PCM
1YHT530004D05 D Section 3
Basic functions
615 series 133
Technical Manual

ABB REF615 L Specifications

General

Type	Feeder Protection Relay
Rated Frequency	50/60 Hz
Weight	Approx. 1.5 kg
Communication Protocols	IEC 61850, Modbus RTU, DNP3
Protection Functions	Overcurrent, Earth fault, Thermal overload, Under/Over voltage, Under/Over frequency
Enclosure	IP20
