5.4.6 Signals
Table 476: BSTGGIO Input signals
Name Type Default Description
SEND_SIG_1 BOOLEAN 0=False Send signal 1 state
SEND_SIG_2 BOOLEAN 0=False Send signal 2 state
SEND_SIG_3 BOOLEAN 0=False Send signal 3 state
SEND_SIG_4 BOOLEAN 0=False Send signal 4 state
SEND_SIG_5 BOOLEAN 0=False Send signal 5 state
SEND_SIG_6 BOOLEAN 0=False Send signal 6 state
SEND_SIG_7 BOOLEAN 0=False Send signal 7 state
SEND_SIG_8 BOOLEAN 0=False Send signal 8 state
Table 477: BSTGGIO Output signals
Name Type Description
RECV_SIG_1 BOOLEAN Receive signal 1 state
RECV_SIG_2 BOOLEAN Receive signal 2 state
RECV_SIG_3 BOOLEAN Receive signal 3 state
RECV_SIG_4 BOOLEAN Receive signal 4 state
RECV_SIG_5 BOOLEAN Receive signal 5 state
RECV_SIG_6 BOOLEAN Receive signal 6 state
RECV_SIG_7 BOOLEAN Receive signal 7 state
RECV_SIG_8 BOOLEAN Receive signal 8 state
SEND_SIG_A BOOLEAN Binary signal transfer sending alarm state
RECV_SIG_A BOOLEAN Binary signal transfer receive alarm state
5.4.7 Settings
Table 478: BSTGGIO Group settings
Parameter
Values (Range) Unit Step Default Description
Signal 1 mode 1=In use
2=In use, alarm sel.
3=Not in use
2=In use, alarm
sel.
Operation mode for signal 1
Signal 2 mode 1=In use
2=In use, alarm sel.
3=Not in use
2=In use, alarm
sel.
Operation mode for signal 2
Signal 3 mode 1=In use
2=In use, alarm sel.
3=Not in use
1=In use Operation mode for signal 3
Signal 4 mode 1=In use
2=In use, alarm sel.
3=Not in use
1=In use Operation mode for signal 4
Table continues on next page
1YHT530004D05 D Section 5
Protection related functions
615 series 559
Technical Manual

ABB REF615 L Specifications

General

Type	Feeder Protection Relay
Rated Frequency	50/60 Hz
Weight	Approx. 1.5 kg
Communication Protocols	IEC 61850, Modbus RTU, DNP3
Protection Functions	Overcurrent, Earth fault, Thermal overload, Under/Over voltage, Under/Over frequency
Enclosure	IP20
