Table 305: DEFHPDEF Monitored data
Name Type Values (Range) Unit Description
FAULT_DIR Enum 0=unknown
1=forward
2=backward
3=both
Detected fault direction
START_DUR FLOAT32 0.00...100.00 % Ratio of start time /
operate time
DIRECTION Enum 0=unknown
1=forward
2=backward
3=both
Direction information
ANGLE_RCA FLOAT32 -180.00...180.00 deg Angle between operating
angle and characteristic
angle
ANGLE FLOAT32 -180.00...180.00 deg Angle between
polarizing and operating
quantity
I_OPER FLOAT32 0.00...40.00 Calculated operating
current
DEFHPDEF Enum 1=on
2=blocked
3=test
4=test/blocked
5=off
Status
4.2.2.13 Technical data
Table 306: DEFxPDEF Technical data
Characteristic
Value
Operation accuracy Depending on the frequency of the current
measured: f
n
±2 Hz
DEFLPDEF
Current:
±1.5% of the set value or ±0.002 x I
n
Voltage
±1.5% of the set value or ±0.002 x U
n
Phase angle:
±2°
DEFHPDEF Current:
±1.5% of the set value or ±0.002 x I
n
(at currents in the range of 0.1…10 x I
n
)
±5.0% of the set value
(at currents in the range of 10…40 x I
n
)
Voltage:
±1.5% of the set value or ±0.002 x U
n
Phase angle:
±2°
Table continues on next page
Section 4 1YHT530004D05 D
Protection functions
302 615 series
Technical Manual
