Parameter Values (Range) Unit Step Default Description
Shot number CBB1 0...5 0 Shot number for CBB1
Shot number CBB2 0...5 0 Shot number for CBB2
Shot number CBB3 0...5 0 Shot number for CBB3
Shot number CBB4 0...5 0 Shot number for CBB4
Shot number CBB5 0...5 0 Shot number for CBB5
Shot number CBB6 0...5 0 Shot number for CBB6
Shot number CBB7 0...5 0 Shot number for CBB7
Str 2 delay shot 1 0...300000 ms 10 0 Delay time for start2, 1st reclose
Str 2 delay shot 2 0...300000 ms 10 0 Delay time for start2 2nd reclose
Str 2 delay shot 3 0...300000 ms 10 0 Delay time for start2 3rd reclose
Str 2 delay shot 4 0...300000 ms 10 0 Delay time for start2, 4th reclose
Str 3 delay shot 1 0...300000 ms 10 0 Delay time for start3, 1st reclose
Str 3 delay shot 2 0...300000 ms 10 0 Delay time for start3 2nd reclose
Str 3 delay shot 3 0...300000 ms 10 0 Delay time for start3 3rd reclose
Str 3 delay shot 4 0...300000 ms 10 0 Delay time for start3, 4th reclose
Str 4 delay shot 1 0...300000 ms 10 0 Delay time for start4, 1st reclose
Str 4 delay shot 2 0...300000 ms 10 0 Delay time for start4 2nd reclose
Str 4 delay shot 3 0...300000 ms 10 0 Delay time for start4 3rd reclose
Str 4 delay shot 4 0...300000 ms 10 0 Delay time for start4, 4th reclose
Frq Op counter limit 0...250 0 Frequent operation counter lockout limit
Frq Op counter time 1...250 min 1 Frequent operation counter time
Frq Op recovery time 1...250 min 1 Frequent operation counter recovery time
Auto init 0...63 0 Defines INIT lines that are activated at
auto initiation
9.4.9 Monitored data
Table 624: DARREC Monitored data
Name
Type Values (Range) Unit Description
DISA_COUNT BOOLEAN 0=False
1=True
Signal for counter
disabling
FRQ_OPR_CNT INT32 0...2147483647 Frequent operation
counter
FRQ_OPR_AL BOOLEAN 0=False
1=True
Frequent operation
counter alarm
STATUS Enum -2=Unsuccessful
-1=Not defined
1=Ready
2=In progress
3=Successful
AR status signal for
IEC61850
ACTIVE BOOLEAN 0=False
1=True
Reclosing sequence is in
progress
Table continues on next page
Section 9 1YHT530004D05 D
Control functions
724 615 series
Technical Manual
