Fault indication Fault code Additional information
Internal Fault
Conf. error,X110
64 Card in slot X110 is wrong type, is
missing or does not belong to the original
composition.
Internal Fault
Conf. error,X120
65 Card in slot X120 is wrong type, is
missing or does not belong to the original
composition.
Internal Fault
Conf.error,X130
66 Card in slot X130 is wrong type, is
missing or does not belong to the original
composition.
Internal Fault
Card error,X000
72 Card in slot X000 is faulty.
Internal Fault
Card error,X100
73 Card in slot X100 is faulty.
Internal Fault
Card error,X110
74 Card in slot X110 is faulty.
Internal Fault
Card error,X120
75 Card in slot X120 is faulty.
Internal Fault
Card error,X130
76 Card in slot X130 is faulty.
Internal Fault
LHMI module
79 LHMI module is faulty. The fault
indication may not be seen on the LHMI
during the fault.
Internal Fault
RAM error
80 Error in the RAM memory on the CPU
card.
Internal Fault
ROM error
81 Error in the ROM memory on the CPU
card.
Internal Fault
EEPROM error
82 Error in the EEPROM memory on the
CPU card.
Internal Fault
FPGA error
83 Error in the FPGA on the CPU card.
Internal Fault
RTC error
84 Error in the RTC on the CPU card.
Internal Fault
RTD card error,X130
96 RTD card located in slot X130 may have
permanent fault. Temporary error has
occurred too many times within a short
time.
For further information on internal fault indications, see the operation manual.
3.2.2 Warnings
In case of a warning, the IED continues to operate except for those protection
functions possibly affected by the fault, and the green Ready LED remains lit as
during normal operation.
Warnings are indicated with the text Warning additionally provided with the
name of the warning, a numeric code and the date and time on the LHMI. The
warning indication message can be manually cleared.
1YHT530004D05 D Section 3
Basic functions
615 series 61
Technical Manual
