ABB REF615 L User Manual

3.14.9.4 Settings
Table 149: SPCGGIO Non group settings
Parameter Values (Range) Unit Step Default Description
Loc Rem restriction 0=False
1=True
1=True Local remote switch restriction
Operation mode 0=Pulsed
1=Toggle
-1=Off
-1=Off Operation mode for generic control point
Pulse length 10...3600000 ms 10 1000 Pulse length for pulsed operation mode
Description SPCGGIO1
Output 1
Generic control point description
Operation mode 0=Pulsed
1=Toggle
-1=Off
-1=Off Operation mode for generic control point
Pulse length 10...3600000 ms 10 1000 Pulse length for pulsed operation mode
Description SPCGGIO1
Output 2
Generic control point description
Operation mode 0=Pulsed
1=Toggle
-1=Off
-1=Off Operation mode for generic control point
Pulse length 10...3600000 ms 10 1000 Pulse length for pulsed operation mode
Description SPCGGIO1
Output 3
Generic control point description
Operation mode 0=Pulsed
1=Toggle
-1=Off
-1=Off Operation mode for generic control point
Pulse length 10...3600000 ms 10 1000 Pulse length for pulsed operation mode
Description SPCGGIO1
Output 4
Generic control point description
Operation mode 0=Pulsed
1=Toggle
-1=Off
-1=Off Operation mode for generic control point
Pulse length 10...3600000 ms 10 1000 Pulse length for pulsed operation mode
Description SPCGGIO1
Output 5
Generic control point description
Operation mode 0=Pulsed
1=Toggle
-1=Off
-1=Off Operation mode for generic control point
Pulse length 10...3600000 ms 10 1000 Pulse length for pulsed operation mode
Description SPCGGIO1
Output 6
Generic control point description
Operation mode 0=Pulsed
1=Toggle
-1=Off
-1=Off Operation mode for generic control point
Pulse length 10...3600000 ms 10 1000 Pulse length for pulsed operation mode
Description SPCGGIO1
Output 7
Generic control point description
Table continues on next page
Section 3 1YHT530004D05 D
Basic functions
136 615 series
Technical Manual

ABB REF615 L Specifications

General

Type	Feeder Protection Relay
Rated Frequency	50/60 Hz
Weight	Approx. 1.5 kg
Communication Protocols	IEC 61850, Modbus RTU, DNP3
Protection Functions	Overcurrent, Earth fault, Thermal overload, Under/Over voltage, Under/Over frequency
Enclosure	IP20
