ABB REF615 L User Manual

Parameter Values (Range) Unit Step Default Description
Operation mode 0=Pulsed
1=Toggle
-1=Off
-1=Off Operation mode for generic control point
Pulse length 10...3600000 ms 10 1000 Pulse length for pulsed operation mode
Description SPCGGIO1
Output 8
Generic control point description
Operation mode 0=Pulsed
1=Toggle
-1=Off
-1=Off Operation mode for generic control point
Pulse length 10...3600000 ms 10 1000 Pulse length for pulsed operation mode
Description SPCGGIO1
Output 9
Generic control point description
Operation mode 0=Pulsed
1=Toggle
-1=Off
-1=Off Operation mode for generic control point
Pulse length 10...3600000 ms 10 1000 Pulse length for pulsed operation mode
Description SPCGGIO1
Output 10
Generic control point description
Operation mode 0=Pulsed
1=Toggle
-1=Off
-1=Off Operation mode for generic control point
Pulse length 10...3600000 ms 10 1000 Pulse length for pulsed operation mode
Description SPCGGIO1
Output 11
Generic control point description
Operation mode 0=Pulsed
1=Toggle
-1=Off
-1=Off Operation mode for generic control point
Pulse length 10...3600000 ms 10 1000 Pulse length for pulsed operation mode
Description SPCGGIO1
Output 12
Generic control point description
Operation mode 0=Pulsed
1=Toggle
-1=Off
-1=Off Operation mode for generic control point
Pulse length 10...3600000 ms 10 1000 Pulse length for pulsed operation mode
Description SPCGGIO1
Output 13
Generic control point description
Operation mode 0=Pulsed
1=Toggle
-1=Off
-1=Off Operation mode for generic control point
Pulse length 10...3600000 ms 10 1000 Pulse length for pulsed operation mode
Description SPCGGIO1
Output 14
Generic control point description
Operation mode 0=Pulsed
1=Toggle
-1=Off
-1=Off Operation mode for generic control point
Pulse length 10...3600000 ms 10 1000 Pulse length for pulsed operation mode
Description SPCGGIO1
Output 15
Generic control point description
Table continues on next page
1YHT530004D05 D Section 3
Basic functions
615 series 137
Technical Manual

ABB REF615 L Specifications

General

Type	Feeder Protection Relay
Rated Frequency	50/60 Hz
Weight	Approx. 1.5 kg
Communication Protocols	IEC 61850, Modbus RTU, DNP3
Protection Functions	Overcurrent, Earth fault, Thermal overload, Under/Over voltage, Under/Over frequency
Enclosure	IP20
