6.6.5 Application
The uncorresponding circuit breaker position means that the actual position of the
circuit breaker’s control switch is unmatched with the real position of the circuit
breaker. In a normal situation, the function is used in cooperation with the
autoreclose function (DARREC). The operate signal can start the autoreclosing
when detecting that the circuit breaker has opened in an unknown situation. If the
function is used as a stand-alone function when an unknown circuit breaker open is
detected, the function output can be used as an information indication for the
supervision station.
6.6.6 Signals
Table 521: UPSCBR Input signals
Name Type Default Description
CB_OPEN_CMD BOOLEAN 0=False CB open command, common
CB_POSCLOSE BOOLEAN 0=False CB position closed
CB_POSOPEN BOOLEAN 0=False CB position open
SI_PWR_ON BOOLEAN 0=False Signal power on
Table 522: UPSCBR Output signals
Name
Type Description
OPERATE BOOLEAN Operate
6.6.7 Settings
Table 523: UPSCBR Non group settings
Parameter
Values (Range) Unit Step Default Description
Operation 1=on
5=off
1=on Operation Off / On
CB open hold delay 300...500 ms 1 300 CB open hold delay time
Operate pulse time 100...20000 ms 1 100 Operate pulse time
Signal pwr on delay 300...500 ms 1 300 Signal power on delay time
6.6.8 Technical data
Table 524: UPSCBR Technical data
Characteristic
Value
Operate time accuracy ±1.0% of the set value or ±20 ms
1YHT530004D05 D Section 6
Supervision functions
615 series 605
Technical Manual
