Name Type Default Description
RESET BOOLEAN 0=False Reset input for LED 3
OK BOOLEAN 0=False Ok input for LED 4
ALARM BOOLEAN 0=False Alarm input for LED 4
RESET BOOLEAN 0=False Reset input for LED 4
OK BOOLEAN 0=False Ok input for LED 5
ALARM BOOLEAN 0=False Alarm input for LED 5
RESET BOOLEAN 0=False Reset input for LED 5
OK BOOLEAN 0=False Ok input for LED 6
ALARM BOOLEAN 0=False Alarm input for LED 6
RESET BOOLEAN 0=False Reset input for LED 6
OK BOOLEAN 0=False Ok input for LED 7
ALARM BOOLEAN 0=False Alarm input for LED 7
RESET BOOLEAN 0=False Reset input for LED 7
OK BOOLEAN 0=False Ok input for LED 8
ALARM BOOLEAN 0=False Alarm input for LED 8
RESET BOOLEAN 0=False Reset input for LED 8
OK BOOLEAN 0=False Ok input for LED 9
ALARM BOOLEAN 0=False Alarm input for LED 9
RESET BOOLEAN 0=False Reset input for LED 9
OK BOOLEAN 0=False Ok input for LED 10
ALARM BOOLEAN 0=False Alarm input for LED 10
RESET BOOLEAN 0=False Reset input for LED 10
OK BOOLEAN 0=False Ok input for LED 11
ALARM BOOLEAN 0=False Alarm input for LED 11
RESET BOOLEAN 0=False Reset input for LED 11
3.4.4 Settings
Table 40: LED settings
Parameter
Values (Range) Unit Step Default Description
Alarm colour 1=Green
2=Red
2=Red Colour for the alarm state of the LED
Alarm mode 0=Follow-S
1=Follow-F
2=Latched-S
3=LatchedAck-F-S
0=Follow-S Alarm mode for programmable LED 1
Description Programmable
LEDs LED 1
Programmable LED description
Alarm mode 0=Follow-S
1=Follow-F
2=Latched-S
3=LatchedAck-F-S
0=Follow-S Alarm mode for programmable LED 2
Table continues on next page
1YHT530004D05 D Section 3
Basic functions
615 series 67
Technical Manual

ABB REF615 L Specifications

General

Type	Feeder Protection Relay
Rated Frequency	50/60 Hz
Weight	Approx. 1.5 kg
Communication Protocols	IEC 61850, Modbus RTU, DNP3
Protection Functions	Overcurrent, Earth fault, Thermal overload, Under/Over voltage, Under/Over frequency
Enclosure	IP20
