ABB REF615 L User Manual

6.5.6 Signals
Table 516: MDSOPT Input signals
Name Type Default Description
BLOCK BOOLEAN 0=False Block input status
POS_ACTIVE BOOLEAN 0=False When active indicates the equipment is running
RESET BOOLEAN 0=False Resets the accumulated operation time to initial
value
Table 517: MDSOPT Output signals
Name Type Description
ALARM BOOLEAN Alarm accumulated operation time exceeds Alarm
value
WARNING BOOLEAN Warning accumulated operation time exceeds
Warning value
6.5.7 Settings
Table 518: MDSOPT Non group settings
Parameter
Values (Range) Unit Step Default Description
Operation 1=on
5=off
1=on Operation Off / On
Warning value 0...299999 h 1 8000 Warning value for operation time
supervision
Alarm value 0...299999 h 1 10000 Alarm value for operation time supervision
Initial value 0...299999 h 1 0 Initial value for operation time supervision
Operating time hour 0...23 h 1 0 Time of day when alarm and warning will
occur
Operating time mode 1=Immediate
2=Timed Warn
3=Timed Warn Alm
1=Immediate Operating time mode for warning and
alarm
6.5.8 Monitored data
Table 519: MDSOPT Monitored data
Name
Type Values (Range) Unit Description
MDSOPT Enum 1=on
2=blocked
3=test
4=test/blocked
5=off
Status
OPR_TIME INT32 0...299999 h Total operation time in
hours
Section 6 1YHT530004D05 D
Supervision functions
602 615 series
Technical Manual

ABB REF615 L Specifications

General

Type	Feeder Protection Relay
Rated Frequency	50/60 Hz
Weight	Approx. 1.5 kg
Communication Protocols	IEC 61850, Modbus RTU, DNP3
Protection Functions	Overcurrent, Earth fault, Thermal overload, Under/Over voltage, Under/Over frequency
Enclosure	IP20
