8.2.5 Monitored data
Table 579: Monitored data for disturbance recorder
Parameter Values (Range) Unit Step Default Description
Number of
recordings
0...100 Number of
recordings
currently in
memory
Rem. amount
of rec.
0...100 Remaining
amount of
recordings
that fit into the
available
recording
memory,
when current
settings are
used
Rec. memory
used
0...100 % Storage mode
for the binary
channel
Time to
trigger
0...604 800 s Time
remaining to
the next
periodic
triggering
8.2.6 Technical revision history
Table 580: RDRE Technical revision history
Technical revision
Change
B ChNum changed to EChNum (RADR's).
RADR9...12 added (Analog channel 9 -12).
RBDR33...64 added (Binary channel 33 - 64).
C Enum update for Channel selection parameters
(DR.RADRx.EChNum.setVal)
Std. enum changes to Clear and Manual Trig
D Symbols in the Channel selection setting are
updated
8.3 Tap changer position indicator TPOSSLTC
8.3.1 Identification
Function description
IEC 61850
identification
IEC 60617
identification
ANSI/IEEE C37.2
device number
Tap changer position indication TPOSSLTC TPOSM 84M
Section 8 1YHT530004D05 D
Measurement functions
660 615 series
Technical Manual

ABB REF615 L Specifications

General

Type	Feeder Protection Relay
Rated Frequency	50/60 Hz
Weight	Approx. 1.5 kg
Communication Protocols	IEC 61850, Modbus RTU, DNP3
Protection Functions	Overcurrent, Earth fault, Thermal overload, Under/Over voltage, Under/Over frequency
Enclosure	IP20
