Function IEC 61850 IEC 60617 IEC-ANSI
Tap changer control with voltage regulator OLATCC1 COLTC 90V
Synchronism and energizing check SECRSYN1 SYNC 25
Condition monitoring
Circuit-breaker condition monitoring SSCBR1 CBCM CBCM
Trip circuit supervision, instance 1 TCSSCBR1 TCS (1) TCM (1)
Trip circuit supervision, instance 2 TCSSCBR2 TCS (2) TCM (2)
Current circuit supervision CCRDIF1 MCS 3I MCS 3I
Fuse failure supervision SEQRFUF1 FUSEF 60
Protection communication supervision PCSRTPC1 PCS PCS
Runtime counter for machines and devices MDSOPT1 OPTS OPTM
Measurement
Disturbance recorder RDRE1 - -
Three-phase current measurement, instance 1 CMMXU1 3I 3I
Three-phase current measurement, instance 2 CMMXU2 3I(B) 3I(B)
Sequence current measurement, instance 1 CSMSQI1 I1, I2, I0 I1, I2, I0
Sequence current measurement, instance 2
CSMSQ2
I1I(B), I2I(B),
I0I(B)
I1I(B), I2I(B),
I0I(B)
Residual current measurement, instance 1 RESCMMXU1 Io In
Residual current measurement, instance 2 RESCMMXU2 Io(B) In(B)
Three-phase voltage measurement VMMXU1 3U 3U
Residual voltage measurement RESVMMXU1 Uo Vn
Sequence voltage measurement VSMSQI1 U1, U2, U0 U1, U2, U0
Three-phase power and energy measurement PEMMXU1 P, E P, E
RTD/mA measurement XRGGIO130 X130 (RTD) X130 (RTD)
Frequency measurement FMMXU1 f f
1) One of the following can be ordered as an option: admittance-based E/F or harmonics-based E/F.
The option is an addition to the existing E/F of the original configuration. The optional E/F has also a
predefined configuration in the IED. The optional E/F can be set on or off. Note: The existing E/F of
the configuration, (DEFx), is always present in the configuration even if it is an option in the order
code sheet.
2) Multi-purpose protection is used for example for. RTD/mA-based protection
1YHT530004D05 D Section 1
Introduction
615 series 31
Technical Manual
