Parameter Values (Range) Unit Step Default Description
CtlStructPWd1 **** Password for Modbus control struct 1
CtlStructPWd2 **** Password for Modbus control struct 2
CtlStructPWd3 **** Password for Modbus control struct 3
CtlStructPWd4 **** Password for Modbus control struct 4
CtlStructPWd5 **** Password for Modbus control struct 5
CtlStructPWd6 **** Password for Modbus control struct 6
CtlStructPWd7 **** Password for Modbus control struct 7
CtlStructPWd8 **** Password for Modbus control struct 8
Table 23: Serial communication settings
Parameter Values (Range) Unit Step Default Description
Fiber mode 0=No fiber
2=Fiber optic
0=No fiber Fiber mode for COM1
Serial mode 1=RS485 2Wire
2=RS485 4Wire
3=RS232 no
handshake
4=RS232 with
handshake
1=RS485 2Wire Serial mode for COM1
CTS delay 0...60000 0 CTS delay for COM1
RTS delay 0...60000 0 RTS delay for COM1
Baudrate 1=300
2=600
3=1200
4=2400
5=4800
6=9600
7=19200
8=38400
9=57600
10=115200
6=9600 Baudrate for COM1
