ABB REF615 L - Binary input settings

Table 28: X110 BIO binary input signals
Name Type Description
X110-Input 1 BOOLEAN Connectors 1-2
X110-Input 2 BOOLEAN Connectors 3-4
X110-Input 3 BOOLEAN Connectors 5-6c
X110-Input 4 BOOLEAN Connectors 7-6c
X110-Input 5 BOOLEAN Connectors 8-9c
X110-Input 6 BOOLEAN Connectors 10-9c
X110-Input 7 BOOLEAN Connectors 11-12c
X110-Input 8 BOOLEAN Connectors 13-12c
Table 29: X110 BIO binary input settings
Parameter Values (Range) Unit Step Default Description
Input 1 filter time 5...1000 ms 5 Connectors 1-2
Input 2 filter time 5...1000 ms 5 Connectors 3-4
Input 3 filter time 5...1000 ms 5 Connectors 5-6c
Input 4 filter time 5...1000 ms 5 Connectors 7-6c
Input 5 filter time 5...1000 ms 5 Connectors 8-9c
Input 6 filter time 5...1000 ms 5 Connectors 10-9c
Input 7 filter time 5...1000 ms 5 Connectors 11-12c
Input 8 filter time 5...1000 ms 5 Connectors 13-12c
Input 1 inversion 0=False
1=True
0=False Connectors 1-2
Input 2 inversion 0=False
1=True
0=False Connectors 3-4
Input 3 inversion 0=False
1=True
0=False Connectors 5-6c
Input 4 inversion 0=False
1=True
0=False Connectors 7-6c
Input 5 inversion 0=False
1=True
0=False Connectors 8-9c
Input 6 inversion 0=False
1=True
0=False Connectors 10-9c
Input 7 inversion 0=False
1=True
0=False Connectors 11-12c
Input 8 inversion 0=False
1=True
0=False Connectors 13-12c
