Table 45: FLTMSTA Non group settings
Parameter Values (Range) Unit Step Default Description
Operation 1=on
5=off
1=on Operation Off / On
Trig mode 0=From all faults
1=From operate
2=From only start
0=From all faults Triggering mode
A measurement mode 1=RMS
2=DFT
3=Peak-to-Peak
2=DFT Selects used measurement mode phase
currents and residual current
Table 46: FLTMSTA Monitored data
Name Type Values (Range) Unit Description
Fault number INT32 0...999999 Fault record number
Time and date Timestamp Fault record time stamp
Start duration FLOAT32 0.00...100.00 % Maximum start duration
of all stages during the
fault
Operate time FLOAT32 0.000...999999.9
99
s Operate time
Breaker clear time FLOAT32 0.000...999999.9
99
s Breaker clear time
Active group INT32 1...6 Active setting group
Shot pointer INT32 0...7 Autoreclosing shot
pointer value
Max diff current IL1 FLOAT32 0.000...80.000 pu Maximum phase A
differential current
Max diff current IL2 FLOAT32 0.000...80.000 pu Maximum phase B
differential current
Max diff current IL3 FLOAT32 0.000...80.000 pu Maximum phase C
differential current
Diff current IL1 FLOAT32 0.000...80.000 pu Differential current
phase A
Diff current IL2 FLOAT32 0.000...80.000 pu Differential current
phase B
Diff current IL3 FLOAT32 0.000...80.000 pu Differential current
phase C
Max bias current IL1 FLOAT32 0.000...50.000 pu Maximum phase A bias
current
Max bias current IL2 FLOAT32 0.000...50.000 pu Maximum phase B bias
current
Max bias current IL3 FLOAT32 0.000...50.000 pu Maximum phase C bias
current
Bias current IL1 FLOAT32 0.000...50.000 pu Bias current phase A
Bias current IL2 FLOAT32 0.000...50.000 pu Bias current phase B
Bias current IL3 FLOAT32 0.000...50.000 pu Bias current phase C
Diff current Io FLOAT32 0.000...80.000 pu Differential current
residual
Table continues on next page
Section 3 1YHT530004D05 D
Basic functions
74 615 series
Technical Manual
