Abov MC96F8204 Series User Manual

153
MC96F8204
ABOV Semiconductor Co., Ltd.
I2CSAR0 (I2C Slave Address 0 Register) : EBH
7
6
5
4
3
2
1
0
I2CSLA06
I2CSLA05
I2CSLA04
I2CSLA03
I2CSLA02
I2CSLA01
I2CSLA00
GCALL0EN
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Initial value : 00H
I2CSLA0[6:0]
These bits configure the slave address 0 in slave mode.
GCALL0EN
This bit decides whether I2C allows general call address or not in I2C slave mode.
0
Ignore general call address
1
Allow general call address
I2CSAR1 (I2C Slave Address 1 Register) : F1H
7
6
5
4
3
2
1
0
I2CSLA16
I2CSLA15
I2CSLA14
I2CSLA13
I2CSLA12
I2CSLA11
I2CSLA10
GCALL1EN
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Initial value : 00H
I2CSLA1[6:0]
These bits configure the slave address 1 in slave mode.
GCALL1EN
This bit decides whether I2C allows general call address or not in I2C slave mode.
0
Ignore general call address
1
Allow general call address
