6243/44 DC Voltage Current Source/Monitor Operation Manual
9.1.1 Voltage/Current Source
9-2
Overall accuracy: Including calibration accuracy, 1-day stability, temperature coefficients, and linearity
1-day stability: Constant source and load
Voltage source /
Voltage limiter
Range Overall accuracy  (% of setting + V)
320 mV
3.2 V
32 V
110 V
0.03 + 200 V
0.03 + 600 V
0.03 + 6 mV
0.03 + 30 mV
Current source /
Current limiter
Range Overall accuracy  (% of setting + A + A Vo / 1 V )
32 A
320 A
3.2 mA
32 mA
320 mA
2 A
0.03 + 10 nA + 300 pA
0.03 + 100 nA + 3 nA
0.03 + 1 A + 30 nA
0.03 + 10 A + 300 nA
0.05 + 100 A + 3 A
0.06 + 1 mA + 30 A
Vo: Compliance voltage (0 V to 110 V)
Voltage source /
Voltage limiter
Range Overall accuracy  (% of setting + V)
320 mV
3.2 V
32 V
110 V
0.01 + 100 V
0.01 + 300 V
0.01 +3 mV
0.01 + 20 mV
Voltage source /
Voltage limiter
Range Overall accuracy  (% of setting + A + A Vo / 1 V )
32 A
320 A
3.2 mA
32 mA
320 mA
2 A
0.015 + 4 nA + 200 pA
0.015 + 40 nA + 2 nA
0.01 + 400 nA + 20 nA
0.01 + 4 A + 200 nA
0.015 + 40 A + 2 A
0.03 + 400 A + 20 A
Vo: Compliance voltage (0 V to 110 V)
