6243/44 DC Voltage Current Source/Monitor Operation Manual
9.1.1 Voltage/Current Source
9-3
Temperature coefficients: At 0 to 50C
Overall accuracy of reverse polarity limiters:
The accuracy of the source value and reverse polarity limiters is obtained
by adding the data in the following table to the overall limiter accuracy.
(However, stability and temperature coefficients do not apply to the fol-
lowing table.)
Source linearity: 0.01% of range
Maximum output current: 2 A up to 32 V, 1 A up to 64 V, 0.5 A up to 110 V
Maximum tracking voltage: 110 V up to 0.5 A, 64 V up to 1 A, 32 V up to 2 A
Voltage source /
Voltage limiter
Range Temperature coefficient  (ppm of setting + V)/C
320 mV
3.2 V
32 V
110 V
15 + 20 V
15 + 50 V
15 + 500 V
15 + 2 mV
Current source /
Current limiter
Range Temperature coefficient  (ppm of setting + A + A Vo / 1 V ) / C
32 A
320 A
3.2 mA
32 mA
320 mA
2 A
25 + 1 nA + 10 pA
25 + 10 nA + 100 pA
20 + 100 nA + 1 nA
20 + 1 A + 10 nA
20 + 10 A + 100 nA
20 + 100 A + 1 A
Vo: Compliance voltage (0 V to 110 V)
Reverse polarity /
Voltage limiter
Range Temperature coefficient  (ppm of setting + V)/C
320 mV
3.2 V
32 V
110 V
0.25 + 8 mV
0.25 + 8 mV
0.25 + 80 mV
0.25 + 300 mV
Reverse polarity /
Current limiter
Range Temperature coefficient  (ppm of setting + A + A Vo / 1 V ) / C
32 A
320 
A
3.2
mA
32 mA
320 mA
2 A
0.25 + 650 nA
0.25 + 6.5 A
0.25 + 65 A
0.25 + 650 A
0.25 + 6.5 mA
0.25 + 65 mA
