2.2.4 Pulse Mode Measurement
2-23
Current measurement at a base value
30. Press the MENU key.
Select TIME in the parameter group by rotating the Data knob. Select the Mea-
sure Delay parameter and set this to 60 ms.
31. Press the EXIT key.
The measurement point moves to point B in Figure 2-8, and the measured cur-
rent, at the base value, appears.
32. Press the MENU key.
Select SOURCE in the parameter group by rotating the Data knob. Select the
Base Value parameter and set this to 0.5 V.
33. Press the EXIT key.
The measured current at the base value changes.
34. Press the OPERATE key.
The OPERATE lamp goes out, and the status becomes Standby (output: OFF).
AZERO
Measure Delay
[60.000ms]
AZERO
IM+1.00000mA
VS:+2.5000V L: 3.0000mA *PLS
AZERO
Base Value
[ 0.5000V]
AZERO
IM+0.50000mA
VS:+2.5000V L: 3.0000mA *PLS
