2.2.4 Pulse Mode Measurement
2-22
24. Press the key and select the Pulse Width parameter by rotating the Data knob.
25. Set the Pulse Width to 50 ms using the same procedure as in steps 22 and 23.
26. Press the EXIT key.
The measurement screen appears.
27. Press the MODE key.
The mode is set to the pulse source mode.
NOTE: The following show the ideal source and measurement values assuming no
errors exist in the measured object (the 1 K resistor), the cable resistance,
and the 6243/44 itself.
Actual measurement values will be different from the values used here due
to the above error factors.
Current measurement at a pulse value
28. Press the OPERATE key.
The OPERATE lamp lights and the source status is set to Operate (output: ON).
The measured current value, at the pulse value of 2 V, appears.
(Measured value at point A in Figure 2-8)
29. Move the cursor with the key and set the source value (pulse value) to 2.5 V
by rotating the Data knob.
The measured current value, at the pulse value of 2.5 V, appears.
AZERO
IM
VS:+2.0000V L: 3.0000mA *PLS
AZERO
IM+2.00000mA
VS*+2.0000V L: 3.0000mA *PLS
AZERO
IM+2.50000mA
VS:+2.5000V L: 3.0000mA *PLS
