6243/44 DC Voltage Current Source/Monitor Operation Manual
2.3.2 Battery Charge Test and Discharge Test
2-39
Press the key and select the Operate Signal parameter by rotating the Data
knob.
Press the key and select Operate OFF In by rotating the Data knob.
Operate Signal is set to Operate OFF In.
Press the key and select the Complete/Busy parameter by rotating the Data
knob.
Press the key and select Complete Out LO by rotating the Data knob.
Complete/Busy is set to Complete Out LO.
11. Press the EXIT key.
The measurement screen returns.
12. Press the VS/IS key.
The function becomes the current source function.
13. Press the DIRECT, 1, 0, 0, 0 mA, and ENTER keys.
The source current is set to 1 A.
14. Press the LIMIT, DIRECT, 1, ., 4, 5, V, and ENTER keys.
The voltage limiter is set to 1.45 V.
NOTE: The following values are for reference only. Actual measurement values will
be different from the values used here due to 6243/44 internal errors and
device characteristics.
15. Press the LIMIT and OPERATE keys.
Charging is performed with the constant current, and the measured current value
appears.
When the charge voltage reaches the specified voltage, the limiter appears
because the constant voltage becomes valid.
AZERO
IM
IS:+1000.0mA L: 1.4500V *DC
AZERO
IM+1000.03mA G0
IS:+1000.0mA L: 1.4500V *DC
AZERO
IM+0621.56mA +lm
IS:+1000.0mA L: 1.4500V *DC
