6243/44 DC Voltage Current Source/Monitor Operation Manual
2.3.2 Battery Charge Test and Discharge Test
2-42
22. Press the OPERATE key.
Pulse discharge starts and the battery voltage during discharge is measured.
When the discharge stop voltage (1.0 V) is reached, the status is switched to
Standby.
Reading out measured data
23. Press the RECALL key to read out the measured values registered during the
discharge.
24. Read out the data of the desired time by pressing the , keys and rotating the
Data knob.
In this case, Period is set to 1 second which means that the Recall No. matches
the elapsed time (seconds).
This completes the discharge test.
AZERO
VM+1.32732V G0
IS:-2000.0mA L: 1.5000V *PLS
AZERO
VM+0.99997V L0
IS:-2000.0mA L: 1.5000V *PLS
AZERO
VM+1.32732V G0
RECALL 0000 L: 1.5000V *PLS
AZERO
VM+1.04781V G0
RECALL 0372 L: 1.5000V *PLS
