6243/44 DC Voltage Current Source/Monitor Operation Manual
2.3.2 Battery Charge Test and Discharge Test
2-41
Press the key and select the Upper Data parameter by rotating the Data knob.
Press the key and press the 1, ., 5, V, and ENTER keys.
Upper Data is set to +1.50000 V.
Press the key and select the Lower Data parameter by rotating the Data knob.
Press the key and press the 1, V, and ENTER keys.
Lower Data is set to +1.00000 V.
Press the key twice or press the MENU key, and select EXT.SIGNAL in the
parameter group by rotating the Data knob.
Press the key and select the Operate Signal parameter by rotating the Data
knob.
Press the key and select Operate OFF In by rotating the Data knob.
Operate Signal is set to Operate OFF In.
Press the key and select the Complete/Busy parameter by rotating the Data
knob.
Press the key and select Complete Out LO by rotating the Data knob.
Complete/Busy is set to Complete Out LO.
Press the key twice or press the MENU key, and select MEASURE BUFFER
in the parameter group by rotating the Data knob.
Press the key and select the Memory Store parameter by rotating the Data
knob.
Press the key and select Normal-ON by rotating the Data knob.
Memory Store is set to Normal-ON.
Press the key and select the Memory Clear parameter by rotating the Data
knob.
Press the key and press the DIRECT key.
Memory Clear is executed.
19. Press the EXIT key. The measurement screen returns.
20. Press the DIRECT, +/-, 2, 0, 0, 0, mA, and ENTER keys.
The source current is set to -2 A.
21. Press the LIMIT, DIRECT, 1, ., 5, V, and ENTER keys.
The voltage limiter is set to 1.5 V.
NOTE: The following values are for reference only. Actual measurement values will
be different from the values used here due to 6243/44 internal errors and
device characteristics.
AZERO
VM
IS:-2000.0mA L: 1.5000V *PLS
To Next Page
