FOCUS 200 PLUS Installation and Setup Guide
13-4
Entry
Number
Description Function
29 (KEY)
BA Keyswitch
(PID gateway
only)
This point type is used for turning a BA group to Day Set or Nite Set
rather than using an operating panel. It requires the connection of a
471998(7187-112) Remote Keyswitch via a Switch Interface Module
SCN 471999. Operating the keyswitch causes an open or close signal
along with the number of the BA group to be sent to the CCC.
30 (RPS)
Remote
Power Supply
This point type is used for monitoring a remote power supply (e.g.,
472381 Power Unit). A loss of AC power to the power supply is
annunciated locally at an operating panel. If the loss of AC extends
beyond 4 hours, it causes an AC Fail signal to be transmitted to the
CCC. However, a low-battery condition, operation of a tamper, or a
point comm fail causes a local trouble annunciation and immediate
transmission of a signal to the CCC.
31 (END)
BA End Delay
(PID gateway
only)
This point type is intended primarily for European applications and
requires the use of a switch to terminate any exit delay time that
remains when the customer closes the exit door. A 471997 Switch
Interface Module and appropriate controlling switch are used for this
purpose.
Note:
Program a maximum exit delay (255 seconds) for the
associated BA group to ensure the customer adequate time for exiting
the premises. Additionally, select the Auto Bell Test option to provide
an audible indication for the persons exiting the premises that the
exit delay has expired.
32 (BLK) BA Blocklock
This point type is intended for use in European applications and
requires the use of a 471997 Switch Interface Module. A special door
lock (Blockschloss) should be installed to prevent the locking of the
exit door if the applicable BA group is not ready to be turned to Nite
set. When the exit door is locked, the BA group is automatically
changed to Nite Set.
If an open occurs, it is processed as a trouble condition. When the
loop is normal, the applicable BA group is in Nite Set. The Ready
outputs of the Switch Interface Module are wired to the internal
solenoid of the lock, which allows the door to be locked if the BA
group is ready to be turned to Nite Set. The customer keyswitch
requires a continuous closure for this application.
35 (ABS) Ambush Start
This point type is used in conjunction with an Ambush End point
type (next item) to initiate an ambush alarm. Failure to operate the
Ambush End point within 4 minutes after tripping the Ambush Start
point causes an ambush alarm.
An example of ambush point application is a bank that does not use
perimeter or interior protection (except for the vault) because
cleaning people come in at unpredictable times. The manager enters
the bank early to perform pre-opening procedures, and wants
protection against being held hostage by hide-ins until opening time
for the vault BA group. Upon arriving the manager triggers the
Ambush Start point, looks around, and then operates the Ambush
End point if everything is OK.
Typically, the contact for this point is installed on the door used for
entering the premises in the morning. If there are detectors that can
be tripped when the customer checks for hide-ins, then the BA group
with these detectors must be turned to Day Set before the entry delay
expires to avoid creating an alarm. The Ambush Start and End
points are not assigned to a BA group and are not associated with the
permanent or temporary schedules. The Ambush Start and End
points use an Ambush Schedule to determine the time frame that
this feature is active.
