ADT Focus 200 Plus Installation And Setup Guide

FOCUS 200 PLUS Installation and Setup Guide
7-10
Table of CCC Signaling
Signal SANS (2) Significance
BA (#) Day Set (3) No BA group (#) turned to Protection Off condition.
BA (#) Nite Set (3) No BA group (#) turned to Protection On condition.
Burglar Alarm (Point #) (4) Yes BA alarm at Point (#).
Burglar Alarm Bypass (Point #) (3) Yes BA Point (#) has been bypassed.
Burglar Alarm Unbypass (Point #) (3) Yes BA Point (#) has been unbypassed.
Burglar Alarm Trouble Yes BA trouble at Point (#). Typically indicates open in PID loop, PID comm
fail, or tamper.
Holdup Alarm (Point #) (4) Yes Holdup alarm at Point (#).
Holdup Alarm Bypass (Point #) (3) Yes Holdup alarm Point (#) has been bypassed.
Holdup Alarm Unbypass (Point #) (3) Yes Holdup alarm Point (#) has been unbypassed.
Holdup Alarm Trouble (Point #) (4) Yes Holdup trouble at Point (#). Typically indicates open in PID loop, PID
Comm fail, or tamper.
Supervisory Alarm (Point #) (4) Yes Supervisory alarm at Point (#).
Supervisory Bypass (Point #) (3) Yes Supervisory Point(s) has been bypassed.
Supervisory Unbypass (Point #) (3) Yes Supervisory Point (#) has been unbypassed.
Supervisory Trouble (Point #) (4) Yes Trouble at supervisory Point (#). Typically indicates open in PID loop, PID
comm fail, or tamper.
Fire Alarm (Point #) (4) Yes Fire alarm at Point (#).
Fire Alarm Bypass (Point #) (3) Yes Fire alarm Point (#) has been bypassed.
Fire Alarm Unbypass (Point #) (3) Yes Fire alarm Point (#) has been unbypassed.
Fire Alarm Trouble (Point #) (4) Yes Trouble at fire alarm Point (#). Typically indicates open in PID loop, PID
comm fail, or tamper.
Untyped Alarm (Point #) (4,6) Yes Untyped alarm at Point (#).
Untyped Bypass (Point #) (3,6) Yes Untyped Point (#) has been bypassed.
Untyped Unbypass (Point #) (3,6) Yes Untyped Point (#) has been unbypassed.
Untyped Trouble (Point #) (4,6) Yes Trouble at Untyped Point (#). Typically indicates open in PID loop, PID
comm fail, or tamper.
Cabinet Tamper Alarm (4) Yes Cabinet tamper has operated.
Operating Panel Tamper Alarm (4) Yes Operating panel tamper has operated.
Printer Interface Tamper Alarm (4) Yes Printer interface unit tamper has operated.
ADT On Premises (3) Yes Signals entry of ADT service code at operating panel; system is in service
mode.
ADT Off Premises (3) Yes Signals entry of Off Premises command at operating panel to terminate
service mode.
Janitor On Premises Yes Key inserted in Janitor keyswitch.
Janitor Off Premises Yes Key removed from Janitor keyswitch.
BA Group (#) Closing Trouble (3) Yes One or more BA protection points in BA group (#) are in alarm after
expiration of exit delay.
BA Group (#) Exit Fail No Customer did not exit after turning on protection in BA group (#).
BA Group (#) Bypass (3) No Protection has been turned on with BA point(s) bypassed in BA group (#).
BA Group (#) No Close No Protection not closed at the end of closing timer timeout at BA group (#).
BA Group (#) Change Closing Time (3) No Close time of BA group (#) has been temporarily changed at an operating
panel.
BA Group (#) Irregular Opening (3) No Alarm due to someone turning a BA group off outside of the scheduled
open period, without having the privilege to do so. The irregular opening
and user ID number are transmitted. (Used with ACS service only.)
Dialer Test Yes Transmitted once upon initialization of control unit, again after 12 hours
have elapsed (as programmed), and thereafter as programmed. Serves to
verify operation of dialing circuitry and integrity of telco line.
