FOCUS 200 PLUS Installation and Setup Guide

10-10

TB2

TB3

TB1

ACIU

RS-485 BUS

CARD READER

KEY READER

ELECTRIC STRIKE

100 FEET MAX.

494461 CABLE (6466-10)

(10-WIRE, #22 AWG)

494470 CABLE

(2-WIRE, #18 AWG)

Figure 10-2: Typical Installation Using Card Reader or Keyreader

TB2

TB3

TB1

ACIU

RS-485 BUS

MARLOK 011-037502

EXTENSION (15 FEET)

(SEE NOTE)

PULL

788-16 FLEXIBLE

ARMORED DOOR

CORD (16")

MARLOK

KEYLOCK

NOTE: MAXIMUM ALLOWABLE CABLE DISTANCE BETWEEN KEYLOCK AND ACIU IS 150 FEET

Figure 10-3: Typical Installation Using a Keylok
