FOCUS 200 PLUS Installation and Setup Guide
7-4
Description of ADEMCO Contact ID Format
When using ADEMCO Contact ID, the FOCUS 200 PLUS system transmits the data in DTMF (Dual
Tone Multi-Frequency). This format requires the 1400hz/2300hz dual tone handshake and the 1400hz
kissoff tone. The signal is comprised of a 4-digit subscriber number, 1-digit event qualifier ("new" or
"restore"), 3-digit event code, 2-digit BA group number, and 3-digit zone number, user number, or
system status number.
ADEMCO Contact ID Reporting
takes the following format:
CCCC QEEE GG ZZZ
where: CCCC = Customer (subscriber) ID
Q = Event qualifier, where:
E = new event, and R = restore
EEE = Event code (3 hexadecimal digits)
GG = BA Group number (system messages show “00”)
ZZZ = Point number reporting the alarm, or user number for Open/Close reports.
System status messages (AC Loss, Walk-Test, etc.) contain zeroes.
Contact ID Event Codes and ADT SIA Report Codes
Description
Printable-Only
Event
ADEMCO
CID
ADT
SIA
System Event
System Reset
X
Reset Memory
X
AC Fail 301 AA
AC Restore 301 AH
AC Fail 4-Hour 926 AT
AC Fail 4-Hour Restore 926 AJ
Telco Line Trouble (Line 1 or Line 2) 350 LT
Telco Line Trouble Restore (Line 1 or Line 2) 350 LR
Low Battery System 302 YT
Low Battery System Restore 302 YR
Change Date
X
Expansion Module
Interactive Keypad Tamper 143 IA
Interactive Keypad Trouble
−
supervision
333 IT
Interactive Keypad Trouble Restore 143 IR
Cardreader Alarm 143 DA
Cardreader Trouble 333 DT
Cardreader Trouble Restore 143 DR
Point Gateway Tamper Alarm 143 EA
Point Gateway Trouble
−
supervision
333 ET
Point Gateway Trouble Restore 143 ER
Printer Tamper Alarm 336 PA
Printer Trouble
−
supervision
333 PT
Printer Trouble Restore 336 PR
RF Low Battery
384 WL
RF Low Battery Restore 384 WR
AC Module Communication Failure
YC
AC Module Communication Failure Restore YO
