22-1
SECTION 22
Equipment
•••••••••••••••••••••••••••••••••••••••••••••••••
In This Section
Basic System Equipment
SIM Sensors
•••••••••••••••••••••••••••••••••••••••••••••••••
Basic System Equipment
The ordering information presented below is for basic items such as the control unit, gateways,
operating panels, etc., as well as replacement parts. For ordering information for all other system
equipment such as PID's, communication modules, sensors, etc., see the equipment's installation
instructions.
Where applicable, each item states its current draw in alarm and standby (normal), as follows:
AI
= Alarm current and
SI
= Standby current.
472462 Control Unit
This is the main control and primary power supply for the FOCUS 200 PLUS System. Consists of:
A steel cabinet, finished in brown, with a key-locked front cover that is hinged.
Plug-in transformer (18VAC/50VA).
A 472368 SIM Gateway and the 471493 housing unit.
A 472402A Backup Dialer.
Cabinet houses a control board/power supply and has space for two separately ordered 12-volt sealed
lead-acid batteries (up to two 17.2AH max.). Control board has facilities for connecting the following
separately ordered items:
A.
Up to sixteen 471210 Operating Panels.
B.
Up to eight 471715 (7187-119) Printer Interface Units; only one printer will be supervised.
C.
Up to eight gateways maximum, consisting of any combination of 472368 SIM and/or 248239 PID
gateways and a maximum of one 472490 RF gateway.
D.
Up to eight 472270 Access Control Interface Units (ACIU) with card/key readers.
The combined total number of operating panels, printers, ACIUs, and gateways must not exceed 31.
Control unit nominal output voltage on quad trunk is 12VDC. See the Power Requirements section to
determine the need for auxiliary power.
AI
=440mA,
SI
=300mA
5422-W Assault Sensor
Assault sensor is required if control unit is mounted outside of protected area. Sensor is installed inside
of control unit housing and serves same function as a lining. Must be wired to tamper terminals of
control unit.
