6-1
SECTION 6
Bell Outputs and Auxiliary Relay
•••••••••••••••••••••••••••••••••••••••••••••••••
In This Section
♦
About the Bell Outputs and Auxiliary Relay
♦
Output Functions
♦
Installing the External Sounders
♦
Programming the Bell Outputs and Auxiliary Relay
•••••••••••••••••••••••••••••••••••••••••••••••••
About the Bell Outputs and Auxiliary Relay
The FOCUS 200 PLUS provides two bell circuits and an auxiliary relay. These outputs are
programmable via the ADEMCO Compass downloader as to when and how they will function.
There are two entries that can be programmed for each output. The first entry is the alarm condition to
be monitored, which will cause the output to operate. The second entry determines whether the output
is to be used to trigger a backup-connected transmitter in the event of a telco line trouble. In this latter
case, the output will not operate for the selected alarm condition unless there is a telco line trouble.
The total alarm current available on auxiliary power #2, auxiliary power #3, the auxiliary relay
terminal 10 (set for wet operation), bell 1, and bell 2 is determined by the transformer used and the
setting of Jumper P4. See the Summary of Connections diagram for the location of Jumper P4.
Transformer
Total Alarm
Current Available
Jumper P4 Setting
50VA (443216 or N8167) Plug-in Transformer 1.5A Pins 2 and 3 shorted
72VA (472404) Wired-in Transformer 2.3A Pins 1 and 2 shorted
Features of the Bell Outputs
• Each bell output is rated at 12VDC, 1.7 amps max.
• Circuits are power-limited by PTC type circuit protectors, which automatically reset when the
short is removed.
• There is an optional setup for supervision.
• Outputs can be used for operating fire and burglary alarm notification appliances.
Features of the Auxiliary Relay
• Form C relay.
• Can be set as either wet (12VDC) or dry contacts (determined by Jumper P3). See the Summary of
Connections diagram for the location of Jumper P3.
• Wet Pins 1 & 2 shorted. Terminal 10 is wet and rated at 12VDC, 1.7A max. power limited.
• Dry Pins 2 & 3 shorted. Terminal 10 is dry and contacts rated at 28VAC/VDC. 2.0A max.
