Wiring the Hardwired Points
The wiring of the hardwired points is divided into four parts:
• Wiring burglary and panic devices to points 1-8.
• Wiring 2-wire smoke detectors to points 1 and 2.
• Wiring 4-wire smoke detectors to points 1-8.
• Wiring points 3 and 4 for style “D” configuration.
Wiring Burglary and Panic Devices to Points 1-8
To wire burglary and/or panic devices to points 1-8 (terminals 25 - 38), perform the following steps:
Step Action
1
Connect normally closed devices
in series
with the high (+) side of the loop.
Note:
The 2K EOL resistor must be connected in series with the devices, following the
last device.
2
Connect normally open devices
in parallel (across)
the loop.
Note:
The 2K EOL resistor must be connected across the loop wires at the last device.
The maximum loop resistance is 100 ohms for points 1 and 2, and 300 ohms for all other points (excluding
the 2K EOL resistor).
Wiring 2-Wire Smoke Detectors to Points 1 and 2
Points 1 and 2 have the added capability of supporting 2-wire smoke detectors. Each point provides
enough standby current (2mA) to power up to 16 of the smoke detectors listed below.
•
2K EOL resistors must be connected across the loop wires of each point at the last detector for fire
points.
•
The alarm current provided by points 1 and 2 will support only one smoke detector each in the alarmed
state.
Compatible 2-Wire Smoke Detectors
You may use up to 16 two-wire smoke detectors each on points 1 and 2 listed in the table below.
DETECTOR TYPE DEVICE MODEL #
Photoelectric, direct wire System Sensor 2400
Photoelectric w/heat sensor, direct wire System Sensor 2400TH
Photoelectric w/B401B base System Sensor 2451
Photoelectric w/heat sensor and B401B base System Sensor 2451TH
Ionization, direct wire System Sensor 1400
Ionization w/B401B base System Sensor 1451
Photoelectric duct detect. w/DH400 base System Sensor 2451
Photoelectric 440354 (3534-2C)
Photoelectric duct detect. w/DH400 base System Sensor 2451
Ionization duct detector w/DH400 base System Sensor 1451DH
Ionization, direct wire System Sensor 1100
Ionization w/B110LP base System Sensor 1151
Photoelectric, direct wire System Sensor 2100
Photoelectric w/heat sensor, direct wire System Sensor 2100T
Photoelectric w/B110LP base System Sensor 2151
Photoelectric w/Thermostat 435021 (3534-2CT)
