ADT Focus 200 Plus Installation And Setup Guide

4-1
SECTION 4
Basic Hardwired Points
•••••••••••••••••••••••••••••••••••••••••••••••••
In This Section
♦
About the Hardwired Points
♦
Wiring the Hardwired Points
♦
Point 8 Bell Box Tamper Configuration
•••••••••••••••••••••••••••••••••••••••••••••••••
About the Hardwired Points
The FOCUS 200 PLUS system has eight built-in hardwired points. The points are individually
assignable to one of eight BA groups. All eight points may be programmed with any point type,
although points 1 and 2 are set up to support 2-wire smoke detectors.
Some additional characteristics of the eight hardwired points:
• EOLR supervision using a 2k resistor.
• Support of normally-open or normally-closed sensors.
• Up to 16 2-wire smoke detectors each on points 1 and 2 (32 total).
• 4-wire smoke or heat detectors on points 1-8 (power to 4-wire smoke detectors must be supervised
with an EOL device).
• Points 3 and 4 may be set for a style “D” configuration.
• Point 8 may be configured as a bell box tamper.
Default point types for the hardwire points are:
Point Description Default Type Gateway # Hard ID
1 Hardwire Point 1 Fire (FA) 8 101
2 Hardwire Point 2 Fire (FA) 8 102
3 Hardwire Point 3 Moveable Delay (MD) 8 103
4 Hardwire Point 4 Moveable Instant (MI) 8 104
5 Hardwire Point 5 Moveable Instant (MI) 8 105
6 Hardwire Point 6 Moveable Delay (MD) 8 106
7 Hardwire Point 7 Moveable Instant (MI) 8 107
8 Hardwire Point 8 Moveable Instant (MI) 8 108
To disable a hardwired point, enter "00" for the point type (NZ) and enter zeroes (0) for the Hard ID.
