Section 14 – Programming
14-7
< ? Grp0 Ut0 Keypad
< BA-
❙
❙
❙
❙
❙
❙
❙
❙
< Previous Change >
< Quit Next >
This screen shows which BA Groups will be automatically opened
(turned off) when a valid ID Code is entered at the operating panel
indicated.
Select
Change
to edit the selections. Enter the number of each BA
Group that will turn off. Entering the number again will erase the
selection.
Select
Next
to move to the operating panel at the next address on
the RS-485 bus.
Continue until all operating panels have been programmed.
< ? Grp4 Ut0 Cardrdr
< BA-
❙
❙
❙
❙
❙
❙
❙
❙
Lg (N) >
< Previous Change >
< Quit Next >
Selecting
Next
at the last operating panel will bring you to this
screen.
This screen is same as the one for the operating panels, except this
is for BA Groups linked to card/key readers.
Select
Change
to edit the selections.
Select
Next
to move to the card/key reader at the next address on
the RS-485 bus.
Selecting
Lg
will toggle between
Yes (Y)
and
No (N)
to log
successful attempts, unsuccessful attempts, openings, and closings
at this card/key reader in the history log.
Selecting
Next
at the screen showing the last card/key reader will
bring you to the
Point Data Info Screen.
Select
Quit
to return to
Action Menu #4.
Programming the System Communication Options
Enter the program mode by entering the Service Code at the operating panel.
< ? Enter choice:
< Lesson Turn on >
< See alarms Reset >
< Quit More >
Action Menu #1
is displayed.
Select
More
three times.
< ? Enter choice:
< Sys info ID codes >
< Name pnt/gps Load >
< Previous First >
Action Menu #4
is displayed.
Select
Load
to continue.
< ? SS-GG-IIII >
< ST P# Remote DLL >
< DTM/Lst Local DLL >
< Quit More >
The
Communication Screen
is displayed.
Select
More
to program the CCC phone number.
< ? Pri Num/Hex Edi
< Pri Phone Num
< Pls/Lst CID >
< Quit Hex Data >
The
CCC Options Screen
is displayed.
Select the
Pls/Lst
key to scroll through the dialing methods. The
choices are:
Pls/Lst = Pulse dialing and loop start
Dtm/Lst = TouchTone dialing and loop start
Pls/Gndst = Pulse and ground start
Dtm/Gndst = TouchTone and ground start
Select the
CID
key to toggle between Contact ID (CID) and
Security Industry Association (SIA) formats.
Select
Pri Phone Num
to program the primary CCC phone
number.
Select
Hex Data
to program the hex data information.
