FOCUS 200 PLUS Installation and Setup Guide
16-2
< ? SS-GG-IIII >
< ST P# Remote DLL >
< DTM/Lst Local DLL >
< Quit More >
The
Communication Screen
is displayed.
Select between
DTM (Tone)
and
Pls (Pulse)
dialing method and
Lst (Loop Start)
and
Gndst (Ground Start)
dial tone method to
reach the Service Terminal.
Select
SS-GG-IIII
to advance to the
System Number Screen
.
Select
Remote DLL
to initiate the downline loading from the
control unit.
Select
ST P#
to advance to the
Service Terminal Phone Number
Screen.
< ? Ser Term Phn #
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
< Pause Dial Tone >
< Quit Enter >
The
Service Terminal Phone Number Screen
is displayed.
Enter the phone number where the service terminal is located.
Select
Pause
and select (wait for)
Dial Tone
as needed. Each
Pause entry is three seconds. Up to 17 digits may be entered.
Select
Enter
when you are finished entering the phone number.
Any digits after the cursor will be erased.
The
Enter
key then changes to
Delete
. Select
Delete
to erase the
displayed phone number.
Select
Quit
to save the displayed phone number and return to the
Communication Screen
.
< ? System Number
SS00 GG000 II0000
< Quit Enter >
The
System Number Screen
is displayed.
Call the CCC to get the System Number.
Enter 2 digits for System Number and select
Enter
.
Enter 3 digits for Group Number and select
Enter
.
Enter 4 digits for Instrument Number and select
Enter
.
Select
Quit
to save the displayed system number and return to the
Communication Screen
.
Downline Loading the Customized Data
The following downline loading procedure applies regardless of whether the point data has been loaded
locally or will be included in the data to be downline loaded.
Until the downline loading has been completed and the "activation byte" has been received, the system
will be locked in a local mode, during which time no signals will be sent to the CCC. As a reminder to
the installer that the system is in the local mode, all operating panels will display:
System in Local Mode
Activation Byte not set
To downline load the system, proceed as follows:
Step Action
1 Call the Service Terminal. This is to ensure that there is a "Read customer unit into the
database" job waiting in the queue for system being installed.
Note:
If there isn't a job waiting in the queue for the system being installed, the system
will perform an Unsolicited Upload.
2 Inform the Service Terminal of the area code and telephone number of the telephone line
connected to Line 2 of the control unit. This is the telephone number that the Service
Terminal will use whenever it contacts the control unit.
3
At any operating panel, enter the
Service Code, More, More, More, Load, Remote
DLL
. The control unit will call the Service Terminal, and the control unit database will be
uploaded to the Service Terminal.
During the upload, the operating panel will display the following message:
Calling ADT to initiate changes.
