ADT Focus 200 Plus Installation And Setup Guide

Section 5 - Gateways
5-23
1
2
3
4
1
2
3
4
5
6
TB1
TB2
BLK
RED
YEL
BLU
{
FROM SIM
GATEWAY
TRUNK
JUMPER
3K EOL
RESISTOR
TA
NO
NC
C
+
12V @ 80mA (max.)
SENSOR
472425 LOOP
INTERFACE MODULE
Figure 5-14: Loop Interface Module Wiring to Powered Sensor
1
2
3
4
1
2
3
4
5
6
TB1
TB2
BLK
RED
YEL
BLU
{
FROM SIM
GATEWAY
TRUNK
NO
NC
C
CONTACT
472425 LOOP
INTERFACE MODULE
LACING / FOIL
LOW SIDE FEED
HIGH SIDE FEED
LOW SIDE RETURN
HIGH SIDE RETURN
BLK
RED
YEL
BLU
Figure 5-15: Loop Interface Module Wiring to Lacing/Foil and Non-powered Sensor
RF Gateway (472490)
The 5800ADT RF gateway provides additional RF points for the FOCUS 200 PLUS security system, up
to 72 points. The RF gateway is designed to be used in conjunction with a 5881H/5881EH/5882H RF
receiver only, and can support up to two receivers. It monitors individual 5800 series transmitters, and
only reports changes in their status to the control panel.
The Unit number for the RF gateway’s identification with the control unit is fixed at Unit #7. Be sure
no other gateway is set to this value.
U
L
The RF gateway and the RF receiver are not listed for UL Commercial Burglary applications.
