FOCUS 200 PLUS Installation and Setup Guide

5-20

RED

BLK

+12V

GND

BLU

YEL

COM+

COM-

33K

TRANSISTOR

SWITCH

RED/W

BLK/W

IN 0

OUT 0

472366 SIM

SEE NOTE 1

IN 2

AL-TBL

BLU/W

TMPR

WHT

TAMPER

33K

NOTE: 1) POINT OPTION 3="N"

2) SIM MOUNTED INSIDE SENSOR OR IN JUNCTION BOX

SPACED NO MORE THAN 6 FEET FROM SENSOR.

Figure 5-10: SIM Wiring to a Sensor

RED

BLK

+12V

GND

BLU

YEL

COM+

COM-

33K

TRANSISTOR

SWITCH

RED/W

BLK/W

IN 0

OUT 0

472366 SIM

SEE NOTE

IN 2

AL-TBL

BLU/W

TMPR

WHT

NOTE: POINT OPTION 3="Y"

BLK

RED

33K

1234

67 8

+ LED C NO TAMPER

FOCUS-VVS

VAULT VIBRATION SENSOR

ADT

TEST

TRANSMITTER

Figure 5-11: SIM Connections to a Vault Vibration Sensor
