Mechanics of Programming
The operating panel provides an interactive display that operates in a manner similar to an automatic
teller machine (ATM). It employs a 19-character, four-line LCD display that shows menu selections,
message prompts, and help screens to guide you through the various operating procedures. Menu items
and other selectable choices are shown on the screen with an arrow (>) that lines up with one of the
four "Selector" buttons on each side of the screen. You make a choice by pressing the button alongside
the item shown on the screen.
Programming of the system is done by selecting a course of action from menu items that appear on a
series of screens known as Action Menus. Entering the valid Service Code will cause the first of four
Action Menus to be displayed. The Action Menus are the starting point for performing all programming
operations.
In order to access the Action Menus, the protection for the BA group associated with the operating panel
where the Service Code is entered must be Off.
Programming Names for the BA Groups
Enter the program mode by entering the Service Code at the operating panel.
< ? Enter choice:
< Lesson Turn on >
< See alarms Reset >
< Quit More >
Action Menu #1
is displayed.
Select
More
three times.
< ? Enter choice:
< Sys info ID codes >
< Name pnt/gps Load >
< Previous First >
Action Menu #4
is displayed.
Select
Name pnt/gps
.
< ? GROUP #1
Group 1
< Prev Change >
< Quit Next >
Group Info Screen
is displayed
.
The default display shows the
info for Group #1.
The top line shows the current name. The second line shows the
group to which this info pertains.
Select
Next
to display the info screen for Group #2. Select
Next
again to display the info screen for Group #3, etc. Select
Prev
to
display the previous group’s info.
Select
Change
to move to the
Character Entry Screen
for the group
displayed.
< ? GROUP #1
Group 1 Done >
< Back CHR Forward >
< Left POS Right >
The cursor is under the first letter of the current name for the
group. Use the third key down on each side to move either
Back
or
Forward
through the alphabet. Use the bottom key on each side to
move the cursor position either
Left
or
Right
through the name.
Select
Done
to save the current name displayed. The system
displays the
Group Info Screen.
Program all group names by selecting either
Next
or
Prev
to move
to another group.
Select
Quit
twice to exit the program mode.
