FOCUS 200 PLUS Installation and Setup Guide

13-12

Types of Input and Output Points and Associated Options

Input Point Type

Mnc

∗

No. Link Group Bypass Option 1

Option 2 ∗∗∗∗

Option 3

BA Fixed FI 1

∗∗

1 thru 8 Y/N

—

NC Contact (Y/N) Self Test

(Y/N)

BA Movable Instant MI 2

∗∗

1 thru 8 Y/N Janitor (Y/N) NC Contact (Y/N) Self Test

(Y/N)

BA Movable Delayed MD 3

∗∗

1 thru 8 Y/N Janitor (Y/N) NC Contact (Y/N) Self Test

(Y/N)

BA Fixed Local FL 4

∗∗

1 thru 8 Y/N

—

NC Contact (Y/N) Self Test

(Y/N)

BA Movable Instant

Daytime Annunciation

MID 5

∗∗

1 thru 8 Y/N Janitor (Y/N) NC Contact (Y/N) Self Test

(Y/N)

BA VVS VVS 6

∗∗

1 thru 8 Y/N Janitor (Y/N) NC Contact (Y/N) Self Test

(Y/N)

BA Movable Instant Chime MIC 7

∗∗

1 thru 8 Y/N Janitor (Y/N) NC Contact (Y/N) Self Test

(Y/N)

BA Movable Delayed Chime MDC 8

∗∗

1 thru 8 Y/N Janitor (Y/N) NC Contact (Y/N) Self Test

(Y/N)

Fire FA 9

∗∗

∗∗∗

Y/N

—

Self Test

(Y/N)

Holdup Special HUS 10

∗∗

∗∗∗

Y/N Suspicion (Y/N) NC Contact (Y/N) Latch (Y/N)

Holdup HU 11

∗∗

∗∗∗

Y/N Suspicion (Y/N) NC Contact (Y/N) Latch (Y/N)

Supervisory SPV 13

∗∗

∗∗∗

Y/N

—

NC contact (Y/N) Self Test

(Y/N)

Janitor Keyswitch-PID only JAN 28

∗∗

1 thru 8 Y/N

———

BA Keyswitch-PID only KEY 29

∗∗

1 thru 8 Y/N

———

Remote Power Supply RPS 30

∗∗

1 thru 8 Y/N

———

BA End Delay-PID only END 31

∗∗

1 thru 8 Y/N

———

BA Blocklock-PID only BLK 32

∗∗

1 thru 8 Y/N

———

Ambush Start ABS 35

∗∗

∗∗∗

Y/N

—

NC Contact (Y/N)

—

Ambush End ABE 36

∗∗

∗∗∗

Y/N

———

Manual Access Pushbutton MAP 60

∗∗

1 thru 8 Y/N Log (Y/N) NC Contact (Y/N) SIM (Y/N)

Exit Pushbutton EXP 64

∗∗

1 thru 8 Y/N

—

NC Contact (Y/N) SIM (Y/N)

Arming ARM 65

∗∗

1 thru 8 Y/N

—

NC Contact (Y/N)

—

Disarm DAR 66

∗∗

1 thru 8 Y/N

—

NC Contact (Y/N)

—

No Alarm Response NAR 67

∗∗

1 thru 8 Y/N

—

NC Contact (Y/N) SIM (Y/N)

Output Point Type

Mnc

∗

No. Link Group Bypass Option 1 Option 2 Option 3

Central Station AC CSC 14

—

1 thru 8 Y/N Complement (Y/N)

——

Service Mode SMC 15

—

∗∗∗

Y/N Complement (Y/N)

——

Telco Fault TFC 16

—

∗∗∗

Y/N Complement (Y/N)

——

BA Schedule SCC 17

—

1 thru 8 Y/N Complement (Y/N)

——

BA Lights LTC 18

—

1 thru 8 Y/N Complement (Y/N)

——

BA Fixed FXC 19

—

1 thru 8 Y/N Complement (Y/N)

——

BA Off OFC 20

—

1 thru 8 Y/N Complement (Y/N)

——

Fire FAC 21

—

∗∗∗

Y/N Complement (Y/N)

——

Supervisory SPC 22

—

∗∗∗

Y/N Complement (Y/N)

——

Holdup HUC 23

—

∗∗∗

Y/N Complement (Y/N)

——

Holdup Suspicion HSC 24

—

∗∗∗

Y/N Complement (Y/N)

——

BA Remote Sonalert RSC 25

—

1 thru 8 Y/N Complement (Y/N)

——

BA Bell and Vault Sensor

Test

TSC 26

—

1 thru 8 Y/N Complement (Y/N)

——

Remote Bell-PID only RBL 27

—

1 thru 8 Y/N Strobe (Y/N) Common BA (Y/N)

—

System Trouble STC 33

—

∗∗∗

Y/N Complement (Y/N)

——

Point Link PLC 34

∗∗

∗∗∗

Y/N Complement (Y/N) Output Link (Y/N)

—

BA Access ACC 37

—

1 thru 8 Y/N Complement (Y/N)

——

Horn/Strobe-SIM only HST 38

—

1 thru 8 Y/N Inhibit BA (Y/N) Common BA (Y/N)

—

Access Denied ACD 59

∗∗

1 thru 8 Y/N Complement (Y/N)

——

∗

Mnemonic

∗∗

If using point-link function, enter the number of point that this point will be linked to.

∗∗∗

Point type must be assigned to a BA group (BA1), otherwise point will cause an FA fault annunciation.

∗∗∗∗

For RF Fire Points, this option must be set for NO. For RF Burglary Points, this option must be set for YES.
