FOCUS 200 PLUS Installation and Setup Guide
19-14
Control Unit Interpretation of Input Point Status & SIM Output Point Status
Point NC Option = NO (1) Point NC
Option = YES (2)
Cross Open Cross or Open
Point Comm.
Failure
Point Tamper
(3)
Point Bypass (4)
Input Point
Assignment
NS DS NS DS NS DS NS DS NS DS Bypass Unbypass
Diagnostic
Test
Fire FA FA FT FT FT FT FT FT FB (5) FU (5) FW
Supervisory SS SS ST ST SS SS STSTSTSTSB (5)SU (5)
Holdup HA HA HT (6) HT (6) HA HA HT HT HT HT HB (5) HU (5)
Holdup Special HT (7) HA (8) HT (6) HT (6) HT (7) HA (8) HT HT HT HT HB (5) HU (5)
Ambush Start HA (9) HA (9) HT HT HA (9) HA (9) HT HT HT HT UB (5) UU (5)
Ambush End HT HT HTHTHTHTUB (5)UU (5)
BA Fixed BABTBABT BABTBABTBABTBB (17)UU (5)
BA Fixed Local (18) (18) BA BT (18) (18) BA BT BA BT BB (17) UU (5)
BA Movable Instant BA (11) BA BT BA (11) BA BT BA BT BB (17) UU (5) BW
BA Movable Instant
Day Annunciation
BA (12) BA BT BA (12) BA BT BA BT BB (17) UU (5) BW
BA Movable Delayed BA (13) (11) BA BT BA (13) (11) BA BT BA BT BB (17) UU (5) BW
BA Movable Instant
Chime
BA (11) BA BT BA (11) BA BT BA BT BB (17) UU (5) BW
BA Movable Delayed
Chime
BA (13) (11) BA BT BA (11) BA BT BA BT BB (17) UU (5) BW
BA Vault Vibration
Sensor
BA (14) BT (11) BA BT BA (14) (11) BA BT BA BT BB (17) BU (10) BW
BA Keyswitch OP CL UA UT UA UT UA UT UB (5) UU (5)
BA Janitor Keyswitch J1 (15) J1 (15) UA UT UA UT UA UT UB (5) UU (5)
BA End Delay UA UT UA UT UA UT UB (5) UU (5)
BA Blocklock OP UA UT UA UT UA UT UB (5) UU (5)
Remote Bell UT (16) UT (16) UT (16) UT (16) UA UT UA UT UB (5) UU (5)
Remote Power Supply UT (16) UT (16) UT (16) UT (16) UA UT UA UT UB (5) UU (5)
SIM Loop Output
Point
UA UT UT UT UB (5) UU (5)
LEGEND:˝
BA Burglar Alarm FA Fire Alarm HU Holdup Alarm Unbypass SU Supervisory Unbypass
BB Burglar Alarm Bypass FE Fire Alarm Bypass JI Janitor In (key inserted) SW Supervisory Diagnostic
BT Burglar Alarm Trouble FT Fire Alarm Trouble JO Janitor Out (key removed) UA Untyped Alarm
BU Burglar Alarm Unbypass FU Fire Alarm Unbypass NS Nite Set UB Untyped Bypass
BW Burglar Alarm Diagnostic FW Fire Alarm Diagnostic OP Opening
CL Closing HA Holdup Alarm SB Supervisory Bypass
UT Untyped Trouble,
Tamper, or Comm Fail
DS Day Set HB Holdup Alarm Bypass SS Supervisory Alarm UU Untyped Unbypass
EA Entry Alarm HT Holdup Alarm Trouble ST Supervisory Trouble
Note: Each transmission to central station includes a tag that specifies cause of alarm or trouble (e.g., cause of trouble
as identified open, tamper, or comm fail).
NOTES:
1.
Typically used for sensor with transfer contacts.
2.
Typically used for sensor with break-only contacts.
3.
Any SIM point with a tamper.
4.
Only with bypass point reporting option.
5.
Bypass and unbypass signals transmitted as event occurs.
6.
Open must be more than 1 minute if using suspicion
option.
7.
All BA groups (except BA1) are Nite Set, otherwise no
transmission.
8.
Any BA group (except BA1) is Day Set, otherwise no
transmission.
9.
Alarm only after 4-1/4 minutes; inside of ambush schedule
and ambush end not activated.
10.
Transmitted automatically at opening if using bypass
point reporting.
11.
Condition is disregarded by control unit.
12.
Causes local audible only.
13.
After entry delay.
14.
Alarm only if BA1 is Nite Set.
15.
Becomes JO (Janitor Off} when key removed.
16.
Cross = AC fail. Open = low battery.
17.
Transmitted automatically at closing if using bypass point
reporting.
18.
Local annunciation only; no CS transmission.
