5702269-C I/O Communication and Control 4-67
Pinnacle™ Plus+ 10 kW
21
recipe ramp
time
Specifies the length of ramping time for a
recipe step (that is, how long the unit will take
to reach the set point you have defined for the
selected recipe step).
Send three data bytes arranged as follows:
• First byte = Recipe step (must be a value
between 0 and 8)
• Second and third bytes = Value between 0
and 60,000 (or between 0 s and 600 s); two
decimal places implied.
Note: If your unit has 100 ms ramp feature
enabled, one decimal is implied. The
range is 0 s to 6000.0 s.
Read back these values with command 181.
3 CSR codes:
0,1,2,4,9
22
recipe set
point
Specifies the set point for a recipe step.
Send three data bytes arranged as follows:
• First byte = Recipe step (must be a value
greater than 0 but no greater than 8)
• Second and third bytes = Value between 0
and the full rated output of the supply.
Note: See the “Specifications” chapter for your
unit's capabilities, and see command 6
for the format of the value.
Read back these values with command 182.
3 CSR codes:
0,1,2,4,9
Table 4-19. AE Bus Commands (Continued)
Command Description Number
of
Transmit
Data
Bytes
CSR
Codes or
Number of
Response
Bytes
