• MENU soft key, which gives you direct access to the menu.
SETTING THE REVERSE TIME, FREQUENCY, AND SET
POINT
To change the reverse time, frequency, or set point, press the soft key under the
display. The units will flash, indicating that you can rotate the knob to change the
value. Once you select a value, it’s only active for editing (changing). You need to
press the soft key again to enter the value. If you press another key before you press
the soft key to enter the value, the new (edited) value will not be accepted. The one
exception is the set point. The set point changes as you rotate the knob.
Soft Keys
Use the soft keys to select whichever menu functions are shown immediately above
them on the two-line display. “Understanding the Menu Options” on page 4-22
explains how to perform these operations from the Pinnacle control panel.
Note: If you’re at the top level, press the MENU soft key to make the menus appear.
Modify Knob
Use the MODIFY knob with the soft keys to change selections and modify values that
appear on the two-line display.
CONTROL PANEL CONTROLS
Use the MODIFY knob and the five unlabeled soft keys that are directly below the
display to select parameters and modify values. To changes parameters using the
menu, the Pinnacle Plus+ unit must be in local control mode (the LOCAL LED will be
illuminated).
Note: When the Pinnacle Plus+ unit is in User or serial (Host) mode, you can view all
the menu items, but you cannot modify any of the items or lock the unit. If you
switch the Pinnacle Plus+ unit to User mode while you are viewing an item in
the menu, you are returned to the output display screen immediately.
Press the MENU soft key when the top level display screen is displayed to cause the
main menu to appear. The main menu contains three menu selections, which are
shown in the figure below. Generally, pressing a soft key causes another level of menu
choices to display (for example, MONITOR, LIMITS, ARC, and CONTROL display
if you press the PROCESS soft key).
